Designation Type Symbol Values/explanations
BMS
±
LON/CAN/IF-
Modul
Wink/service
±
Local/remote
operation
±
Bus address
±
IF gateway val A
±
IF gateway val C
±
IF gateway val E
±
IF gateway val F
IN1 (sensor input)
IN1 (sensor value
range)
±
IN1 (value range)
IN2
±
IN2 active/inactive
±
IN2 (value range)
PID parameters
Settings for Building Manage-
ment System (BMS) – building
automation
The wink function permits the
identification of a device in the
BMS network. A "wink" is execu-
ted by confirmation.
BMS local operation
BMS remote operation
Setting of bus address
Specific settings of the IF-
Module, depends on protocol
type
Specific settings of the IF-
Module, depends on protocol
type
Specific settings of the IF-
Module, depends on protocol
type
Specific settings of the IF-
Module, depends on protocol
type
Settings for sensor input 1
Display of sensor value range 1
Setting of the value range
Possible values: 0...10 V/2...10 V/
0...20 mA/4...20 mA
Setting for external setpoint
input 2
ON
External setpoint input 2 active
OFF
External setpoint input 2 inac-
tive
Setting of the value range
Possible values: 0...10 V/
2...10 V/0...20 mA/4...20 mA
Settings for PID control
Display conditions
Incl. all sub-menus, only dis-
played when BMS is active
Only displayed when LON,
CAN or IF-Module is active
Temporary state, automatic
reset to remote operation
after 5 min
Further information can be
found in the installation and
operating instructions of the
IF-Modules
Further information can be
found in the installation and
operating instructions of the
IF-Modules
Further information can be
found in the installation and
operating instructions of the
IF-Modules
Further information can be
found in the installation and
operating instructions of the
IF-Modules
Not displayed in the manual
control mode (incl. all sub-
menus)
Not displayed with PID con-
trol
Not displayed when IN2 =
inactive
Only displayed when PID
control is active (incl. all sub-
menus)
