ASSEMBLY INSTRUCTIONS
8. Pour one pack of glass rocks (L) over the burner.
Do not cover ignition screen (M) with glass rocks (L).
Use a glove when handling glass rocks.
WARNING
DO NOT COVER THE IGNITION SCREEN when
placing the glass rocks into the fire bowl. Always
keep Ignition Screen visible. This screen must be
clear and free of obstructions at all times to insure
proper operation.
Screen
Do not place glass
rocks on screen.
Keep screen clear.
CAUTION
GLASS ROCKS - Use a glove when handling glass rocks.
1. Do not light or use gas unit if glass rocks are wet. Make sure glass rocks are completely dry before lighting as intense heat could
cause the rock to crack.
2. Glass rocks could hit a person's face or eyes during the initial startup of this unit. Keep away from the appliance for the first 20
minutes after lighting.
3. Use only Pleasant Hearth / GHP Group, Inc. factory-authorized glass rocks. The use of any glass rock that is not factory-
authorized can be dangerous and will void your warranty.
9. Attach the handle (A) to the table lid (B) with one
M4x6 screw (DD) and one washer ø4 (EE).
Tighten with phillips screwdriver (II).
Hardware Used
DD
Screw M4 X 6
EE
Washer ø4
II
Phillips screwdriver
10. Place the table lid (B) over the fire pit.
Total fire pit installation is complete.
Caution: Never place a table lid on the
fire pit when in use. Ensure the fire pit
has cooled before placing a table lid over
the fire pit.
8
CORRECT
glass rocks completely. Otherwise the flame may be
extinguished occasionally. See the Figure CORRECT
INCORRECT
9
X 1
X 1
10
12
M
The burner of the firebowl must be covered by
and INCORRECT for reference.
B
L
L
A
B
DD
EE
