Hirose 12-pin connector: colors and pins for power supply
When connecting an open-ended cable to a Hirose 12-pin connector, ensure
that the pins are connected to the correct wire as described in the table below.
Note that for powering up the camera, the power connection is necessary only.
1
9
2
8
10
3
11
12
7
4
6
5
The complete pin assignment is explained in the technical manual. Download it
from
https://www.alliedvision.com
, from the dropdown menu choose
Documentation
Pin
Color
Signal
Camera
1
Blue
GND
Camera
2
Red
Power
: select
I/O
Level
GND for
In
RS232 and
ext. power
8 to
In
30.0 VDC
>
Support
Technical
.
Manta
Description
Ground for
camera
power supply
and RS232
Camera
power supply
15
