Specifi Cations - Sony TRINITRON KV-38DRC2 Manual De Instrucciones

Television system
American TV standard, NTSC
Channel coverage
VHF: 2-13/ UHF: 14-69/ CATV: 1-125
Picture tube
®
FD Trinitron tube
Visible screen size
36-inch picture measured diagonally
Actual screen size
38-inch measured diagonally
Antenna
75 ohm external terminal for VHF/UHF
Supplied Accessories
Remote Commander RM-Y184
Two Size AA (R6) Batteries
Optional Accessories
Connecting cables: RK-74A, VMC-810S/820/830HGS, VMC-720M,
VMC-810S/820S, YC-15V/30V, YC-15/30HG, RKG69HG, RKC-515HG
U/V mixer: EAC-66
TV Stand: S U-36XBR45
Design and specifi cations are subject to change without notice.
SPECIFICATIONS
Power requirements
Number of inputs/outputs
1)
Video
2)
S Video
3)
Audio
4)
Audio Out
5)
Y,P , P
B R
Monitor Out
Control-S (in/out)
Speaker output(W)
Power Consumption(W)
In use(Max)
In standby
Dimensions(W/H/D)
(mm)
(in)
Mass
(kg)
(lbs)
— 4 —
KV-38DRC2 KV-38DRC2C
120V, 60 Hz 220V, 50 Hz
4
3
6
1
2
1
YES
7.5W x 4
245W
2W
994 x 754.5 x 622 mm
9 45 1
39 / x 29 / x 24 / in
64 64 2
108 kg
238 lbs.
TruSurround
by
incorporated under license from SRS Labs, Inc. and are protected
under United States Patent Nos. 4,748,669 and 4,841,572 with
numerous additional issued and pending foreign patents. Pur-
chase of this product does not convey the right to sell recordings
made with the TruSurround technology.
SRS (SOUND RETRIEVAL SYSTEM)
The SRS (SOUND RETRIEVAL SYSTEM) is manufactured by
Sony Corporation under license from SRS Labs, Inc. It is covered
by U.S. Patent No. 4,748,669. Other U.S. and foreign patents
pending.
The word 'SRS' and the SRS symbol
marks of SRS Labs, Inc. BBE and BBE symbol are trademarks of
BBE Sound, Inc. and are licensed by BBE Sound, Inc. under U.S.
Patent No. 4,638,258 and 4,482,866.
KV-38DRC2 / 38DRC2C
1) 1 Vp-p 75 ohms unbalanced, sync negative
2) Y: 1 Vp-p 75 ohms unbalanced, sync negative
C: 0.286 Vp-p (Burst signal), 75 ohms
3) Y: 1.0 Vp-p, 75 ohms, sync negative;
PB: 0.7 Vp-p, 75 ohms
PR: Vp-p, 75 ohms
4) 500 mVrms (100% modulation), Impedance: 47 kilohms
5) More than 408 mVrms at the maximum volume setting (variable)
More than 408 mVrms (fi x)
TruSurround is a trademark of
SRS Labs, Inc. SRS and the SRS
symbol are registered trademarks
of SRS Labs, Inc. in the United
™
SRS
States and in select foreign coun-
®
tries. SRS and TruSurround are
are registered trade-
