PCB Jumpers and LEDs: Original Main PCB

Figure 2-12 shows the locations of IND310drive jumpers and LEDs on the original
main PCB.
All internal jumpers have been factory set and need not be reset unless a change in
scale configuration or communication peripherals occurs. The IND310drive
terminal as delivered from the factory can be configured five ways:
•
•
•
To set up a configuration for:
Single analog or dual analog
Single POWERCELL
Single analog (Scale 1) and
a single POWERCELL (Scale 2)
Two POWERCELL load cell boards
Single POWERCELL load cell board as Scale 1 and a
single analog load cell board as Scale 2
Two single analog load cell boards
Dual analog load cell board
2-12
J1
LED 2
W3
W4
Figure 2-12: Jumper and LED Locations, Original Main PCB
Single analog
Dual analog
Dual POWERCELLs
• Single analog and one POWERCELL
Single POWERCELL
•
Use table:
LED 3 (top),
LED4 (bottom)
W2
LED 1
2-7
2-8
2-7 (Single analog)
2-8 (POWERCELL)
2-8 and 2-9
2-7 (POWERCELL-Scale 1)
2-9 (Single analog-Scale2)
2-6 and 2-9
2-7
