6.4
Static front camera
calibration
Static camera calibration
configuration
To perform the static front camera calibration,
you must first proceed with its configuration ac-
cording to the selected vehicle.
Static camera calibration configuration
1 Select the "ADAS" functions menu
from the scantool
2 Select the "Static front camera cali-
bration" function and press the "Next"
icon
3 Preliminary information is displayed on
the scantool display, such as:
3.1 when calibration is to be per-
formed,
3.2 preliminary conditions
The operator must read this informa-
tion. Then press the "Next" icon
4 Indications relating to the positioning
of the Digital ADAS 2.0 structure with
respect to the selected vehicle are
shown on the display
Then press the "Next" icon
