Signal targets for E_DIGITAL
Signal Meaning
E_DIGITAL.0 Digital input 8 (DI/DO 8)
E_DIGITAL.1 Digital input 9 (DI/DO 9)
E_DIGITAL.2 Digital input 10 (DI/DO 10)
E_DIGITAL.3 Digital input 11 (DI/DO 11)
E_DIGITAL.4 Digital input 12 (DI/DO 12)
E_DIGITAL.5 Digital input 13 (DI/DO 13)
E_DIGITAL.6 Digital input 14 (DI/DO 14)
E_DIGITAL.7 Digital input 15 (DI/DO 15)
E_DIGITAL.8 Digital input 0 (DI 0)
E_DIGITAL.9 Digital input 1 (DI 1)
E_DIGITAL.10 Digital input 2 (DI 2)
E_DIGITAL.11 Digital input 3 (DI 3)
E_DIGITAL.12 Digital input 4 (DI 4)
E_DIGITAL.13 Digital input 5 (DI 5)
E_DIGITAL.14 Digital input 6 (DI 6)
E_DIGITAL.15 Digital input 7 (DI 7)
<1> Used in telegrams 390, 391 and 392.
1 2
DO: CU_G, CU_S
PROFIdrive - E_DIGITAL interconnection
Interconnection
parameters
<2> p2082[0] = r0722[8]
p2082[1] = r0722[9]
<2>
p2082[2] = r0722[10]
<2>
<2> p2082[3] = r0722[11]
<2> p2082[4] = r0722[12]
<2> p2082[5] = r0722[13]
p2082[6] = r0722[14]
<2>
p2082[7] = r0722[15]
<2>
p2082[8] = r0722[0]
p2082[9] = r0722[1]
p2082[10] = r0722[2]
p2082[11] = r0722[3]
p2082[12] = r0722[4]
p2082[13] = r0722[5]
p2082[14] = r0722[6]
p2082[15] = r0722[7]
<2> Can be set via p0728 as input (DI) or output (DO).
3 4
[Function diagram] [Function diagram]
Internal status word signal target
<3>
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
<3> Pre-assignment, can be freely changed.
5 6
Function diagram
fp_2498_54_eng.vsd
S120/S150/G130/G150
06.06.08 V04.03.01
PROFIdrive sampling time
<1>
Refer to [1020.7]
Inverted
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
7 8
- 2498 -
