3
Slide Head Track
Retainer tight
tight
to Side
Jamb.
NOTICE
·
DO NOT drill deeper than
3/4" into head jamb. Doing
so will result in product
damage.
Apply
Sealant
in holes.
Position Head Track Retainer tight to side jamb in existing screen track. Drill 1/8" holes - 3/4" deep in head jamb, clear
debris, apply sealant in holes, reposition Head Track Retainer, and fasten with #8 x 2" Stainless Steel Screws.
9 2 0 5707
Existing
Screen Track
ONLY 3/4"
deep.
4
th
1
st
Position Head
Track Retainer.
2
nd
Drill 1/8" holes,
3/4" deep using
Head Track Retainer
as a guide.
5
th
Reposition
Head Track
Retainer.
11
200/400 Series
#8 x 2" Stainless Steel Screw
NOTICE
·
Protect surfaces from tool contact.
Failure to do so could result in
surface marring or product damage.
Remove Head
Track Retainer.
Fasten
Head Track
Retainer
with #8 x 2"
Stainless
Steel Screw.
3
rd
6
th
