Protection and state instruction
Function
Input low voltage alarm
Input low voltage
shutdown
Input over voltage
shutdown
Overload shutdown
Over temperature
shutdown
Output shortcircuit
Specification
DC 12 V model
Input voltage
DC 24 V model
Output voltage
Output frequency
USB output
Continuous power
Peak power
Output wave
Total harmonic distortion
Efficiency
No load current
12V Input
Input low
voltage alarm
24V Input
Input low
12V Input
voltage
24V Input
shutdown
Input over
12V Input
voltage
24V Input
shutdown
Overload shutdown
Working temperature
Heat dissipation method
Cable
State description
LED light Alarm
Green on
Alarma
Red off
Green on
No alarm
Red on
Green on
No alarm
Red on
Green on
No alarm
Red on
Green on
Alarm
Red on
Green on
No alarm
Red off
300-PSW
300 W
600 W
360-390 W
AC output
When the voltage of battery returns to
YES
related range, alarm stops automatically.
When the voltage of the battery return
NO to related range the inverter will restart
work, green light on, red light off.
When the voltage of the battery return
NO to related range the inverter will restart
work, green light on, red light off.
Reduce the load to related range. The
NO inverter will restart work, green liht on,
red light off
When the inside temperatura return to
NO related range the inverter will restart to
work, green light on, red light off.
When short circuit stopped the inverter
NO
restarts to work automatically.
600-PSW 1200-PSW
DC 11 ~ 15 V
DC 22 ~ 30 V
AC 220 V ± 10%
50 Hz. ± 3 Hz.
DC 5 V. 500 mA
600 W 1200 W
1200 W 2400 W
Pure sine wave
< 3 %
> 85 %
< 0.45 A.
DC 10.2 – 10.8 V
DC 20.4 – 21.6 V
DC 9.2 – 9.8 V
DC 18.4 – 19.6 V
DC 15 – 16 V
DC 30 – 32 V
720-780 W 1440-1560 W
5 – 35 °C
Fan
Red / Black battery cable. Yellow earth wire
Restart work method
1500-PSW 3000-PSW
1500 W 3000 W
3000 W 6000 W
1800-1950 W 3300-3600 W
