10. SPARE PARTS LISTS
Pos.
1 Protective grating
2 Gas fitting
3 Fan blade
4 Thermostat socket
5 Main switch Ventilate – 0 – Heat
6 Motor / Fan
7 Ignition electrode
8 Switching unit
9 Infrared flicker sensor IRD 1020
10 Sensor cable for IRD 1020
11 Magnet holder for IRD 1020
12 Differential pressure monitor
13 Safety temperature controller (STC)
14 Automatic gas firing unit DVI 980
15 Release button
16 Relay
17 Fuse
18 Reset capacitor
19 Nozzle
20 Ignition cable
21 Combustion chamber
22 Burner head
Name
Use only OEM parts for repairs.
NG-L-30 NG-L-50
Item No. Item No.
----- -----
101299 103417
----- -----
100423 100423
100818 100818
102390 101152
100756 100756
100294 100294
100217 100217
100720 100720
100719 100719
101300 101300
100219 100219
103946 103946
103718 103718
100728 100728
101132 101132
103569 103569
per table 1 per table 1
1-00153 1-00153
3-00346 3-00795
- 13 -
NG-L-80 NG-L-100
Item No. Item No.
----- 100984
103417 103417
----- 101002
100423 100423
100818 100818
1-02240 103552
100756 100756
100294 100294
100217 100217
100720 100720
100719 100719
101300 101300
100219 100219
103946 103946
103718 103718
100728 100728
101132 101132
103569 103569
per table 1 per table 1
1-00153 1-00153
3-00795 3-00269
