Backyard Storage Solutions 16602-T Manual De Montaje página 19

WALL #17
Top
Parte Superior
SP x2
(180 cm)
End View
Vista terminal
WALL #17
See Page 8 For Building Tip!!!
Some confi gurations will
utilize 2 "C" panels here
Algunas confi guraciones
utilizarán 2 paneles "C" aqui.
12"
(30 cm)
Nail Inside Panel
Clave dentro del
Flush
panel
Nivelado
End View
Vista terminal
TJ x2
71"
24" 24"
(61 cm) (61 cm)
48"
(122 cm)
Top
Parte Superior
Flush
Nivelado
144"
(366 cm)
6"
(15 cm)
Nail Perimeter
Clave el peri-
metro
3"(7.6 cm)
x 32
UM x7
24"
(61 cm)
24"
(61 cm)
24" 24"
(61 cm) (61 cm)
2"(5 cm)
x 135
1"
(2.5 cm)
144"
(366 cm)
140-1/2"
(357 cm)
17
MURO #17
24"
(61 cm)
24"
(61 cm)
24"
(61 cm)
140-1/2"
(357 cm)
20-1/2"
24"
(52 cm)
(61 cm)
92-1/2"
(235 cm)
MURO #17
¡Ver la página 8 para un consejo!!!
A x3
3-1/2"
(8.9 cm)
In some cases this wall will use
2-24" and 2-48" panels, in the fol-
lowing order 24-24-48-48
Esta pared puede utilizar 2-61cm
y 2-122cm paneles, en osta orden
61-61-122-122
20-1/2"
(52 cm)
3-1/2"
(8.9 cm)
