1RC
COMMON
P24V
N15V
P15V
N6.2V
INPUT
N1 - N15V
PROBE TERMINAL BLOCK (1TB)
- 24 V 10 Ma (steady state) supply to
Pre-amplifier
- Increases to 40 mA current pulse with
Probe signal
NO
DESCRIPTION
SCALE
NTS
DRAWN
WWC
CHECKED
WWC
APPROVED
WWC
Coneccions Externo
FIN
COARSE
CAL ZERO
DAMPING
I
I MAX
0
10
SEC.
DATE
DATE
TITLE
06/10/01
06/10/01
INTERCONECCION
06/10/01
1 2 3 4 5
L N G
115 VAC
(220 VAC)
50 / 60 Hz
PROBE TERMINAL BLOCK 21TB)
- 115 VAC 50/60 Hz at 10 VA max.
- 0 to 10 VDC Output 5 mA max.
- 4 to 20 mA Output into 0 to 750 ohms.
1RC supplies L.C.D. Meter or Alarm Board with
power and signal voltages
FILE 20374311
NCT-2
PLOT
JOB NO.
6 7
8
- + -
0 - 10V 4 - 20 mA
DRAWING NO.
1:1
1-30112Z-DU-B
REV
0
