9

Troubleshooting

9.1

Safety

See Chapter 2 Safety.
9.2

Service address

See Chapter 1 Important basic information.
9.3

Position and labelling of fuses

See wiring diagram.
9.4

First measures for troubleshooting

Disturbances /
error messages
When pressing the
button Start (17), the
swivel arm (6) drives
out and drives in
again after a short
period of time
without filling.
When pressing the
button Start (17), the
swivel arm (6) does
not drive out.
Original operating manual Bag-in-Box Filler BBF6
06.07.2021
Possible reason(s)

When the swivel arm (6) is
extended, the rear end
position sensor of the
pressurised air cylinder is
not actuated

When the swivel arm (6) is
retracted, the front end
position sensor of the
pressurised air cylinder is
not actuated
Troubleshooting
Remedy

Adjust rear end position
sensor of the pressurised
air cylinder

Adjust front end position
sensor of the pressurised
air cylinder
