C.1
C.2
C.3
D.1
By removing the screw 2, you can
remove the head from the mounting
base for angle adjustments.
Hold the base to the installation
surface and mark the screw holes
with a pencil.
Hold the base to the surface you
want to install it on
holes with a pencil
the marks into the wall
dowels drive screws through the
holes of the mounting base.
Attention: asure that you use the
correct dowels for
surface the dowels in the package
contents are for normal concrete
walls.
Put back the front cover. Important:
the arrows must match.
turn the front cover to close it
correctly (tighten the weatherproof
seal)
mark the screw
drill holes on
insert the
your desired
