English (Original Instructions); Health Hazards - Luna AIW3/4 TH-6 Manual De Usuario

1
Pos.
1. Anvil
2. Support handle
3. Air outlet opening
4. Speed regulator
5. Air inlet opening
6. Trigger
7. Torque regulator
English
Code no
Luna
Square drive
Bolt capacity
Free speed
Max. torque (3 steps)
Max. torque (3 steps)
Max. reverse torque (3 steps)
Max. reverse torque (3 steps)
Hammer mechanism
Sound level (EN ISO 15744:2002)
Vibration (ISO 8662-7:1997)
Min. hose size
Air inlet
Air consumption at 100% int.*
Air consumption at 15% int.*
Air consumption at 100% int.*
Air consumption at 15% int.*
Length
Weight
*At 6.2 bar
3
2
4
7
20321 -0109
No AIW3/4"TH-6
inch 3/4
mm M18-M27
r.p.m. 5 000
Nm 870/1300/1740/2170 870/1300/1740/2170
ft-lb 640/960/1280/1600 640/960/1280/1600
Nm 2170
ft-lb 1600
type Twin hammer
dB(A) 102
m/s 9.3
2
inch 3/4
inch 1/2
l/min 1580
l/min 237
cfm 55.8
cfm 8.4
mm 473
kg 6.3
22
6
Impact wrench in straight performance with an extended anvil (Pos.1). Designed for
maintenance and service works. High torque capacity 360° swivelling exhaust (Pos.3).
Equipped with a speed regulator (Pos.4) torque regulator (Pos. 7) and support handle
(Pos.2).
Supplied as standard with set of locking pins and pin stoppers for the sockets.
• User of the tool should always take care of his and other persons' safety. The user
must always use personal protective equipment.
•
Wear safety goggles, in order to reduce risk of eye injuries that could be caused by
flying sawdust, dust and sparkles.
• Inhalation of dust can be harmful to health. Wear a suitable visor or breathing appa-
5
ratus, when working in a dusty environment.
• In case of continuous work wear safety gloves protecting against the cold air.
• In order to avoid eventual aural injuries, always use ear protection when using the
tool.
• The user must always pay attention to the fact that continuous use of rotating and
impact producing manual tools could result in baneful influence on health caused by
the vibration.
• Ergonomic load: Work with the tools related to recurrent, monotone movements
-0208
and uncomfortable body positions may cause back, scruff, arm, knee and other joint
AIW1"TH-6
injuries.
1
M22-M33
5 000
2170
1600
Twin Hammer
102
9.3
3/4
1/2
1580
237
55.8
8.4
473
6.3
Description

Health hazards
