SUPORTE AIRON WALL MF 40 V22 / MF 40 V44
B A
C
BASIC PLATE
-Start fixating the Base Plate (01) putting the screws for screwdrivers Ø 4,8 x 50mm (03) in the holes indicated in
the illustration above, without totally tightening them.
-Level the Base plate (01) using the oval hole spaces (B and C). After leveling it, start giving a final tightening in
all screws, starting from the upper rounded hole (A).
Positioning the TV set onto the Base Plate
- Superficially lean back the upper part of your
TV set.
03
-Transfer the holes in the Base Plate (01) onto the wall.
B
Note in the picture on the side that the vertical oval
holes (b) must be facing up.
-The function of the oval holes is to allow a small level
adjustment (rotation), when tightening the fixating
screws thus, the drill on the wall must be done as
centralized in relation to the oval mark as possible.
C
a
b
- Fit the upper border
the upper edge
- Return you TV set to the upright position and
firmly tighten both of fixating screws
of "Plasma supports" on
(a)
of the "base plate".
(b)
.
(03)
10
