4.

INSTALLATION

4.1. Mounting the MixRite

Important!
- The MixRite inlet and outlet must reach the inlet and outlet pipes.
- The MixRite must be positioned above the liquid additive container.
- Do not install the MixRite above an acid container, (fumes may damage the
MixRite) and protect it from possible contact with corrosive products.
- The MixRite must be protected from frost and excessive heat.

4.1.1. Mounting on Wall

MixRite 2.5
Phillips MixRite
screw (x2) Bracket
Lug (x2)
MixRite
Bracket
