DMX-512 FUNCTION
The device adopts international standard DMX-512 signal, with totally 4 channels, details
as below:
Channel
CH1 0-255
CH2 0-255
CH3 0-255
CH4 0-255
CH5 0-255
CH6 0-255
CH7 0-255
CH8 0-255

SIGNAL CONNECTION

This product is assembled with DMX input and output 3 pins XLR socket, while all
connection is that Pin 1 is connected to the ground, Pin 2 is connected the negative pole
signal, Pin 3 is connected the Positive pole signal.
This product applies for 3 pins XLR socket, the connection of many units
as following:
1. No overloading connection, the same branch without over 32 units.
2. Terminal matching connection， connect a resistance of1 20 ohms between the Foot 2
and Foot 3 of DMX output Pin 3 socket of the last equipment of the branch.
DMX-512 ADDRESS CODE SET
Lighting NO.
Original address（ID Value）
1 0
2 1
3 2
4 3
5 4
6 5
7 6
8 7
9 8
10 9
··· ······
All manuals and user guides at all-guides.com
512 Value Function
Controlled A fish
Controlled B fish
Controlled C fish
Regulated the speed of A,B,C fishes
Changed A pattern
Changed B pattern
Changed C pattern
Regulator speed of A,B and C
Pattern changed
Binary Code Dialing（ON）
10
10.5
10.6
10.5.6
10.7
10.5.7
10.6.7
10.5.6.7
10.8
10.5.8
······
2
