Roof Rake Assembly
5
H
K
B
Insert 1 3/4" bolt (H) and a curved washer (K) through
aluminum pole (B), lower curved washer (K) and
brace (E).
Note: Make sure center of brace is aligned with lower
hole in aluminum pole.
7
I
Insert button snap (I) into extension pole (C). Repeat for
additional poles (D).
(continued)
C
6
H
K
H
x2
L
1
L
G
G
Attach wingnut (G) and washer (L) to 1 3/4" bolt (H).
Before proceeding to next step, tighten all hardware on
blade and pole.
8
B
1
Push down button snap (C) and insert into aluminum
pole (B). Repeat for additional poles if needed.
5
C
2
2
