Especificaciones - Astell & Kern ACRO CA1000T Guia Del Usuario

User Guide
Especifi-
caciones
Especificaciones generales
Product Name ACRO CA1000T
Model PPR42
Body Material
Aluminum
Display
4.1inch 720x1280
Supported Audio WAV, FLAC, WMA, MP3, OGG, APE, AAC, ALAC, AIFF,
Formats DFF, DSF, MQA
MQA playback
Services (Tidal Masters), Local files, External USB, MQA-CD(ripped)
Sampling Rate PCM : 8kHz ~ 768kHz (8/16/24/32bits per Sample)
DSD Native: DSD64(1bit 2.8MHz), Stereo / DSD128(1bit 5.6MHz), Stereo /
DSD256(1bit 11.2MHz), Stereo / DSD512(1bit 22.4MHz), Stereo
CPU Quad-core
DAC ESS ES9039MPRO x2 (Dual-DAC)
Vacuum Tube
KORG Nutube 6P1 x2
Output level [Low] Unbalanced 2Vrms / Balanced 4Vrms (Condition No Load),
[Mid] Unbalanced 4Vrms / Balanced 8Vrms (Condition No Load),
[High] Unbalanced 6Vrms / Balanced 12Vrms (Condition No Load),
[Super] Unbalanced 8Vrms / Balanced 15Vrms (Condition No Load)
RCA 2Vrms (Condition No Load), XLR 4Vrms (Condition No Load)
Decoding
Support up to 32bit / 768kHz Bit-to-Bit playback
Headphone Outputs
Unbalanced (3.5mm, 6.35mm) / Bananced (2.5mm, 4.4mm)
Analog Inputs 4.4mm Balanced x1
Outputs RCA (Stereo pair) x1, XLR (Stereo pair) x1
Digital Inputs
Coaxial x1, Optical x1, USB(Type-C) x1
Outputs Optical(3.5mm) x1, USB(Type-C) x1
Wi-Fi 802.11 a/b/g/n/ac (2.4/5GHz)
Bluetooth
V5.0 (A2DP, AVRCP, Qualcomm® aptX™ HD, LDAC)
Dimensions 4.12"(104.9mm)[W] x 1.77"(45mm)[H] x 6.13"(155.8mm)[D]
Weight about 34.56oz (980g)
Feature Enhancements
Firmware update supported (OTA)
Especificaciones de audio
Frequency Response ±0.031dB (Condition : 20Hz~20kHz) Unbalanced / ±0.029dB (Condition : 20Hz~20kHz) Balanced /
±0.033dB (Condition : 20Hz~20kHz) RCA / ±0.002dB (Condition : 20Hz~20kHz) XLR
±0.079dB (Condition : 20Hz~70kHz) Unbalanced / ±0.029dB (Condition : 20Hz~70kHz) Balanced /
±0.080dB (Condition : 20Hz~70kHz) RCA / ±0.008dB (Condition : 20Hz~70kHz) XLR
S/N 108dB @ 1kHz, Unbalanced / 112dB @ 1kHz, Balanced / 121dB @ 1kHz, RCA / 128dB @ 1kHz, XLR
Crosstalk
-115dB @ 1kHz, Unbalanced / -112dB @ 1kHz, Balanced / -138dB @ 1kHz, RCA / -145dB @ 1kHz, XLR
THD+N 0.004% @ 1kHz, Unbalanced / 0.002% @ 1kHz, Balanced / 0.0005% @ 1kHz, RCA / 0.0003% @ 1kHz, XLR
IMD SMPTE 0.0007% 800Hz 10kHz (4:1) Unbalanced / 0.0007% 800Hz 10kHz (4:1) Balanced /
0.0007% 800Hz 10kHz (4:1) RCA / /0.0007% 800Hz 10kHz (4:1) XLR
Output Impedance 3.5mm, 6.35mm (1ohm) / 2.5mm, 4.4mm (2ohm) / RCA (4ohm) / XLR (9ohm)
Clock Jitter 25ps (Typ)
Reference Clock Jitter
70ps
Memoria
Built-in Memory
256GB
External Memory microSD (Max. 1TB) x1
Batería
Capacity 10,100mAh 3.8V Li-Polymer
Sistemas operativos compatibles
Supported OS Windows 10, 11 (32/64bit) / MAC OS X 10.7 and up
* Las especificaciones de audio se basarán en OP AMP.
69
Varios
