Wiring
L1 L2 L3
Jumpers
L1 L2 L3
Temperature sensor bts 01
• 1x RJ 11 black flat cable
Communication
• 2x RJ 45 black flat cable
rcc 02/03 / multi-units :
xtender, vt, vs, bsp, xcom
The device must be installed in accordance with local standards and regulations in force.
EN
FR
L'appareil doit être installé conformément aux normes et réglementations locales en vigueur.
DE
Das Gerät muss gemäß den geltenden örtlichen Normen und Vorschriften installiert werden.
ES
El dispositivo debe instalarse de acuerdo con las normas y regulaciones locales vigentes.
8
Auxiliary Contacts
AUX1
AUX2
NC C NO
L
N
L
N
Remote control rcm 10
• 1x RJ 11 black flat cable
:
Bus termination
Battery connection
*Bat+ connection
(provided)
• 70mm
2
cable M8, 10Nm
fusible
• 50mm
2
ceramic
washer
• 35mm
2
cable M8, 10Nm
washer
bolt
Protection device (battery side)*
M8 x 30
• 150A
xtm 2600-48
M10 cable
• 250A
xtm 1500-12
*Internal fuse provided on bat+, recommended external fuse
AC out connection
AC in connection
• Up to 3x10mm
• Up to 3x10mm
2
cable, 1.6Nm
Protection device to protect cables
Up to 56Aac, circuit breaker type B
Protection device AC
Protection device to protect people
50Aac, circuit breaker type B
Up to 56Aac, RCCB/RCD, check
Overvoltage protection, SPD
earth scheme
Overvoltage protection, SPD
M8
T10
xtm 1500-12 xtm 2000-12 xtm 3500-24
cable M8, 10Nm
xtm 2400-24 xtm 4000-48
xtm 2600-48
/ 200A
xtm 2400-24 xtm 4000-48
/ 300A
xtm 2000-12 xtm 3500-24
Lithium batteries
communication
BMS CAN
CAN
Li
xcom CAN
2
cable, 1.6Nm
BAT+, M8
BAT-, M10
9
