F R O N T PA N E L
1. Power button
2. MicroSD memory card slot
3. USB Type-C
4. USB 3.1 port
5. Analog audio jack (3.5mm)
R E A R PA N E L
1. WiFi antenna connector
2. LAN (RJ45) ports
3. USB 3.1 port
4. DisplayPort
5. HDMI port
6. Power input (DC19V)
S E T T I N G U P YO U R ZOTAC Z B OX
1. Connecting antenna for Wi-Fi
2. Connecting to a wired home network
3. Connecting USB 3.1 devices
4. Connecting a DisplayPort display
5. Connecting an HDMI display
6. Connecting the power adapter and
turning on the system
2
1
2
2
1
3
2
2
1
3
1
2
3
4
4
5
3
6
4
5
6
4
5
6
5
3
