Atco-Qualcast CLASSIC ELECTRIC 30 Instrucciones De Operación página 14

GB • Printed in England • BA F 016 L69 839 • QX elctric • OSW 02.02
F016 L69 839.book Seite 2 Freitag, 22. Februar 2002 10:04 10
Cylinder Mower CLASSIC
ELECTRIC 30
Part number F016 313 4..
Rated power 340 W
Blade width 30 cm
Height of cut 10 – 35 mm
Grassbox capacity 32 l
Self Propelled –
Rake –
Weight 23.5 kg
Protection class
/ II
Serial Number See serial No 9 (rating plate) on machine
Intended Use
This product is intended for domestic lawn
mowing.
Introduction
This manual gives instructions on the correct as-
sembly and safe use of your machine. It is im-
portant that you read these instructions care-
fully.
When fully assembled the machine weighs ap-
proximately 23.5 – 28 kg. If necessary, obtain as-
sistance to remove from packaging.
Take care when carrying the mower to the
lawn, as the blades are sharp.
Delivered Items
Carefully remove the machine from its packag-
ing and check that you have all the following
items:
– Lawnmower with handle assembly
– Handle spindle
– Wing nuts
– Grassbox
– Operating instructions
When parts are missing or damaged, please contact
your dealer.
14 • F016 L69 839 • TMS • 05.02.02
Product Specification
CLASSIC CLASSIC
ELECTRIC 30 S ELECTRIC 35 S
F016 313 5.. F016 313 6.. F016 302 5..
340 W 340 W
30 cm 35 cm
10 – 35 mm 10 – 35 mm
32 l 32 l
• •
– –
24.5 kg 27 kg
/ II / II
1 Handlebar
2 Switch lever
3 Safety button
4 Handle bottom
5 Grassbox
6 Cable restraint**
7 Mains plug**
8 Ventilation slots
9 Serial Number
10 Height of cut knob
**Country specific
Not all of the accessories illustrated or described are
included as standard delivery.
- 2
English
WINDSOR 12 S WINDSOR 14 S
F016 314 1..
340 W 340 W
30 cm 35 cm
10 – 35 mm 10 – 35 mm
32 l 32 l
• •
• •
24.5 kg 28 kg
/ II / II
Operating Controls
