OPERATION
5. With charger's power supply cord unplugged,
connect battery charger into machine as shown.
Flip up hood support stand and rest hood on stand
to promote ventilation (Figure 21).
FIG. 21
6. Plug the charger's power supply cord into a
grounded wall outlet (Figure 22).
Grounded
3 Hole Outlet
Ground Pin
FIG. 22
FOR SAFETY: Do not operate charger unless cord
is properly grounded.
WARNING: Keep Sparks And Open Flame
Away. Keep Battery Hood Open When Charging.
NOTE: Once the charger is connected, machine
becomes inoperable.
7. The charger will automatically begin charging and
shut off when fully charged.
8. When disconnecting charger, always unplug
charger from wall outlet first.
9. After charging, recheck the battery fluid level (A) in
each battery cell. The level should be 1 cm (3/8 in)
from the bottom of sight tubes (B). Add distilled
water if needed. DO NOT OVERFILL (Figure 23).
B
FIG. 23
12
A
Home Find... Go To..

MACHINE MAINTENANCE

To keep machine in good working condition, simply
follow machines daily, weekly and monthly
maintenance procedures.
FOR SAFETY: Before leaving or servicing
machine, stop on level surface and turn off
machine.
WARNING: Disconnect Battery Cables Before
Servicing Machine.
ATTENTION: Contact an Authorized Service
Center for machine repairs. Machine repairs
performed by other than an authorized person will
void your warranty.

DAILY MAINTENANCE

(Every 4 Hours of Use)
1. Remove and clean pad/brush.
2. Remove and clean float shut-off screen located in
recovery tank (Figure 24).
FIG. 24
3. Drain and rinse tanks thoroughly. After draining
tanks, hinge recovery tank until you can see
vacuum intake hole at rear of tank. Remove any
debris in hole if necessary.
4. Raise squeegee and wipe it down with a dry cloth.
Store squeegee in the up position to prevent
squeegee damage.
5. Clean machine with an all purpose cleaner and
damp cloth.
ATTENTION: Do not power spray or hose off
machine. Electrical component damage may
result.
6. Recharge batteries if necessary.
FS-2000 Battery Scrubber (10- -04)
