SIGNAL RESPONSE
The gure below shows Audio, Numeric,
Bar graph, and Polarity signal response to:
1. No object
2. One small deep metal target, and
3. A second larger and shallower metal
object.
Ground
LCD Visual
Speaker Audio
1.
Motion
No Object
The LCD display indicates both the
numeric- digital and analog bar-graph
response as the locator passes over the
ground.
2. 3.
Object
- 26 -
