INSTRUCTIONS / INSTRUCCIONES / INSTRUCTIONS
5.
Use closest upright to open side
Locked position
Use ball stud closest to opening side
(Shown 18 CU.FT Model)
Open the cargo carrier and raise the upright on each end into the locked
position on the front and back. Be sure to use the closest upright and position it
into the closest bracket to open side.
6.
Mounting Bracket
Mounting Plate
Place the mounting bracket (A) through the
Then slide the mounting plate (C) over the
pre-drilled holes from below the vehicle
threaded posts inside the cargo carrier.
cross rails as shown above.
Knobs
Thread two knobs (B) evenly and loosely - do not tighten all the way at this
point. Repeat steps until all 4 mounting brackets (A), all 4 mounting plates
(C) are in place and the 8 knobs (B) are loosely in place. Make sure cargo
carrier is centered on vehicle. Then tighten all 8 knobs evenly and securely.
6
