Eastman
®
Montaje de la plataforma HD Edge
PF-04832-MS
ITEM PART NO.
1
333-34-6Z
2
PF-30680
3
PF-30631-MS Cover Panel, Middle
4
PF-40492-MS HD Edge Platform Frame
5
PF-21874
6
PF-21873
7
332-36-10
8
335-34-20
9
632-64
10
PF-21872
11
PF-13423
12
PF-13422
13
9027-0203
14
331-38-16
15
402-38
16
410-38
17
PF-30629
18
100-19-7
MS: tamaño de la máquina
18
DESCRIPTION
Screw,Skt.Btn.Hd.
1/4-20x3/8, Zinc
Cover Panel, End
Locking Bracket
Roller Plate
Screw,Skt.Flt.Hd.
5/16-18x5/8
Screw,Skt.Hd. 1/4-20x1&1/4 16
Ring,Rtn.Extrnl. 1.000 Shaft 8
Block, Brg Edge Platform
Shaft, Edge Platform, 2-Roll 4
Spacer,
1.5ODx1.011IDx.062W
Bearing,Platform
1.0IDx2.0ODx.84W
Screw,Hex.Hd. 3/8-16x1
Washer, Lock 3/8
Washer, Flat 3/8
Actuator Mount, Motor Side 1
5000# PFS
Pin, Air Cylinder End
QTY.
ITEM PART NO.
24
19
11-6031-1
2
20
332-86-4
1
21
211-93
1
22
410-080
4
23
11-1186
4
24
313-86-18
16
25
402-080
26
20C3-31
27
11-1167
4
28
9060-024
29
342-36-6
12
30
PF-30628
8
31
CH-72
32
11-1189
2
33
PF-21845
2
34
PF-21844
2
35
PF-13397
36
410-36
37
402-36
1
38
331-36-12
DESCRIPTION
Motor, Actuator, 90VDC
#1125,8" 1/2 SPD
Screw,Skt.Flt.Hd. #6-32x1/4 2
Nut,Elastic Hex Light #8-32 4
Washer, Flat #8
Switch, Micro
Screw,Rd.Hd. #6-32x1&1/8
Washer, Lock #8
Screw, #8-32x3.21,
Front-Rear Bearing
Box, Limit Switch
Collar,1.25IDx1.75ODx.5LG 1
Screw,Skt.Set 5/16-18x3/8
Actuator Mount, Rod Side
5000# PFS
Plate, Nut
Switch, Out Of Cloth
Mtg Bracket, Limit Switch
Slide, Edge Control
Cam, Edge Control
Washer, Flat 5/16
Washer, Lock 5/16
Screw, Hex.Hd. 5/16-18x3/4 4
Los números del artículo son solo para
referencia. Especifique el NÚMERO DE
PIEZA al ordenar piezas de repuesto.
QTY.
1
14
3
6
6
4
3
2
1
3
1
1
1
1
4
4
Formulario CR-50-0479HP
