SIMPLE MANUAL
HIGH POWER
SPEAKER SYSTEM
Please read this manual carefully before operating your set and retain it for
future reference.
To view the instructions of advanced features, visit http://www.lg.com and
then download Owner's Manual. Some of the content in this manual may
differ from your unit.
MODEL
RM1
MFL71456203
1908_Rev01 Copyright © 2019 LG Electronics Inc. All Rights Reserved.
RM1-NK.APANLLK_SIM_ENG_SPA(MEX)_MFL71456203.indd 1-4
Rear panel
a
b
h
i
j
k
a Display window h SD CARD slot
You can play sound files by connecting the SD card.
b 1 (Standby)
Turns the power on or off. i USB Port
You can play sound files by connecting the USB device.
F (Function)
Selects the function and input source. j MIC (Microphone) 1/2 Jack
C/V (Skip/Search)
k AC IN socket
- Skips backward or forward.
- You can search a folder by pressing and holding.
N (Play/Pause) Fully charge the device before using.
Starts or pauses playback.
REPEAT
l LINE IN
Listens to your files repeatedly.
Connect a portable device.
c MASTER VOLUME
Adjusts speaker volume.
d BASS
Adjusts BASS sound level when setting USER EQ.
e TREBLE
Adjusts TREBLE sound level when setting USER EQ.
f MIC (Microphone) ECHO
Adjusts echo volume.
g MIC (Microphone) VOLUME
Adjusts microphone volume.
www.lg.com
Additional Information
Specifications
Refer to the main label on
Power Requirements
the unit.
Refer to the main label on
Power Consumption
the unit.
Approx. 255 mm X
Dimensions (W x H x D)
380 mm X 250 mm
Bus Power Supply (USB) 5 V 0 500 mA
Amplifier
25 W RMS
(Total RMS output power)
c d e f g
Battery
2600mAh
l Battery capacity
(Built-in rechargeable battery)
Approx. 4 hours
It may vary depending on the
Operating time
battery status and operational
conditions.
Approx. 4 hours
It can be varied depending on
Charging time
the conditions of the battery
or operation.
Design and specifications are subject to change without
notice.
LED Display table
LED displays and descriptions are as belows.
LED Display Description
HELLO
BYE
USB
SD
LINE
BT
READ
ONE
ALL
NO FILE
CONNECTED
NOT SUPPORT
LOW BATTERY
