Item Description
If this function is enabled, when VoIP call is occurred, the other data will be automatically reduced traffic which across the
Smart-QoS:
internet in order to guarantee the voice bandwidth.
You can configure your bandwidth what the Max byte of download and upload of ADSL modem rate.
Bandwidth control:
Setting G.723 / G.729 voice compression size. Quality and Packet size can adjust by you want.
G.723/G.729
Bandwidth:
Some Router support TOS(Type of Service), when you enable the TOS function, the router will process those packets
IP TOS:
firstly.(default is disable)

4.2.3 Direct call (Peer to Peer) setup

If you don't registered Gatekeeper or SIP proxy server, you can make call by Peer to Peer. For SIP or H.323, setting the dialing plan, and can make
direct call.
Overview of the Dialing Plan
The "Dialing plan" need setting when the user use the method of Peer-to-Peer H.323 (SIP) VoIP call or registering H.323 Gatekeeper (SIP Proxy
Server) Mode. The H.323(SIP) Dialing Plan has two kinds of directions: Outgoing (call out) and Incoming (call in).
1. Outgoing Dial Plan:
Peer-to-Peer Call Mode: Effective Registering to H.323 Gatekeeper (SIP Proxy Server) Mode: Effective
2. Incoming Dial Plan:
Peer-to-Peer Call Mode: Effective
Registering to H.323 Gatekeeper (SIP Proxy Server) Mode:
The leading number would
When you use direct call, you must setting your VoIP protocol firstly. Use direct call, you should setting the same protocol both of UA. Both of UA
must support dial plan function. Some ATA don't support Dialing plan, it maybe let direct call failed.
In the "Outgoing Dial Plan Configurations" settings: Maximum Entries : 50
. "Outbound number" is the leading digits of the call out dialing number.
. "Length of Number" has two text fields need filled: "Min Length" and "Max Length" is the min/max allowed length you can dial.
. "Delete Length" is the number of digits that will be stripped from beginning of the dialed number.
to H.323 Gatekeeper (SIP Proxy Server)
register
