Craftsman 917.370605 Manual Del Propietário página 45

HONDA 4-CYCLE ENGINE
CYLINDER BARREL
KEY PART
NO. NO. DESCRIPTION
1 12000-Z0L-406 Cylinder Assembly
12000-Z0L-840 Cylinder Assembly
3 12310-Z0J-000 Cover, Cylinder Head
12311-ZL8-D00 Cover, Head
12311-ZL8-000 Cover, Head
4 12355-ZL8-000 Cover, Breather
(Breather Valve Assembly)
5 90013-883-000 Bolt, Flange (#6 x 12)
(CT200)
6 90014-952-000 Bolt, Flange (#6 x 14)
(CT200)
7 91201-ZL8-003 Oil Seal (25.4 x 62 x 6)
8 98079-55846 Spark Plug (BPR5ES)
(NGK)
10 12209-ZM0-003 Seal, Valve Stem
11 14711-ZL8-000 Valve, Intake
(Technostar)
14711-Z0J-000 Valve, Intake (Rocknel)
14711-Z0J-800 Valve, Intake
12 14721-ZL8-000 Valve, Exhaust
13 14751-ZL8-000 Spring, Valve
14 14771-Z0J-000 Retainer, Valve Spring
CARBURETOR
KEY PART
NO. NO. DESCRIPTION
1 16010-883-015 Gasket Set
2 16013-ZL1-003 Float Set
3 16015-Z0L-881 Chamber Set, Float
5 16028-ZE0-005 Screw Set
16028-ZK7-S91 Screw Set
7 16100-Z0L-852 Carburetor Assembly
(BB62Z B)
8 16155-ZM0-013 Valve, Float
9 16166-ZM0-003 Nozzle, Main
10 16211-ZL8-000 Insulator, Carburetor
11 16212-ZL8-000 Gasket, Insulator
13 16228-ZL8-000 Gasket, Carburetor
15 93500-05006-0H Screw, Pan (#5 x 6)
16 99101-124-0600 Jet, Main (#60)
99101-124-0620 Jet, Main (#62)
99101-124-0650 Jet, Main (#65)
26 16951-Z0L-000 Guide, Air
All manuals and user guides at all-guides.com
CONTROL
KEY
NO.
1 16551-ZM0-010 Arm, Governor
2 16555-Z0L-801
3 16561-Z0L-000
4 16562-ZM0-000 Spring, Throttle Return
10 90015-ZE5-010 Bolt, Governor Arm
13 94050-06000
15 93892-04012-00 Screw, Washer Head
16 94103-04000
CRANKSHAFT
KEY
NO.
3 13310-ZM0-610 Crankshaft
5 90402-ZL8-000
RECOIL STARTER
KEY
NO.
1 28400-Z0L-V20ZA
Rope)
8 28461-ZL8-003
9 28462-Z0L-V20
11 90201-ZM0-000 Nut, Flange (6 mm)
45
MODEL NUMBER GCV160-LAOS3B
PART
NO. DESCRIPTION
Rod, Governor
Spring, Governor
Nut, Flange (6 mm)
(#4 x 12)
Washer, Plain (4 mm)
PART
NO. DESCRIPTION
Washer, Thrust
PART
NO. DESCRIPTION
Starter Assembly,
Recoil, "NH1" (Long
(Black)
Grip, Recoil Starter
Rope, Recoil Starter,
"Long Type" (Black)
