INSTRUCTION MANUAL
EN
CLOTH SHAVER GDS6
GENERAL DESCRIPTION
1. Height adjuster
2. Shield
3. Blade
4. Body
5. Lamp
6. ON/OFF switch
7. Handle
8. Supply socket
9. Container
10. Little brush
11. Battery cover

TECHNICAL DATA

- power: 3W
- voltage supply:
100-240V ~ 50Hz
- battery: 2 x Ni-MH 600mAh
- loading time: 8 hours
INTENDED USE
The GDS6 shaver is designed to refresh various types of clothing and fabrics. Removing so called flocs or fuzz from
the material makes it look fresh again.
The device can be used not only on clothes, but also on curtains, blankets or upholstered furniture. The distance
pad with adjustable cutting length allows you to safely remove flocs without worrying that the refreshed material
will be damaged.
HOW TO USE THE APPLIANCE
- The appliance can be used after charging the battery or by connecting to the mains
– Power cable should be properly connected to the socket (8).
- The appliance is equipped with an internal battery. Charging time is about 8 hours.
- In order to increase the battery life-span charging should be done in one uninterrupted cycle after full
discharging
- Charge is indicated by a control light (5). The indicator light does not turn off when the battery is charged.
- After charging, the appliance should be disconnected from the mains and the power cord should be unplugged
from the socket (8).
BATTERY REPLACEMENT
1. Open the battery case.
2. Take out the used battery
3. Install new baterry by putting one side of the battery bebeath the battery baffle and then pressing down the
other side.Used batteries should be thrown away the containers specially designed for this purpose
HANDLING
- before start-up fix a shield (2).
Do not switch on the shaver when the shield is loose.
Note. The appliance does not operate in case the shield is fixed in an improper manner.
- The shaver starts the operation after the switch (6) has been slid into the „1" position.
- move the shaver along clothes laying on a flat surface
- In order to switch a unit off slide the switch (6) into „0" positio
•
