Osram OPTOTRONIC Manual De Instrucciones

OPTOTRONIC
1)
OTi DALI 35/220-240/700 NFC TW L
OTi DALI 75/220-240/1A4 NFC TW L
A
7)
Input
6)
PE
DA
DA

Installing and operating information (SELV driver): Connect only
LED load type. LED module will be switched off when output voltage
drops below 15V or rises above 54V. Wiring information (see fig. A):
The light fixture maker is the final responsible for the proper PE con-
nection. The DALI interface provides basic insulation against mains.
Do not connect channel 1 and channel 2 of the output, otherwise the
LED driver or LED module can be damaged. No galvanic separation
between CH1 and CH2. Output current adjustment = via programming
software using the DALI interface or via Near Field Communication
(NFC) in mains off mode only. Connect the unit to a DALI programmer
(i.e. DALI magic) and run at a PC the software Tuner4TRONIC – then
follow the instructions. ww.inventronicsglobal.com. For Near Field
Communication please refer to Tuner4TRONIC, then follow the
instructions. www. inventronicsglobal. com. Setting of DALI DT8 or DALI
DT6 (2-channel mode) by Tuner4TRONIC software. Unit is perma-
nently damaged if mains is applied to the terminals 21-24. Lines 21-24
max. 2 m whole length excl. modules.
LED Power Supply
®
8)
Output
3)
picture only for reference, valid print on product 5)
picture only for reference, valid print on product 5)
9)
10)
Emergency lighting: This LED power supply complies with EN 61347-
2-13 Annex J and is suitable for emergency lighting fixtures according
to EN 60598-2-22. Hereby, Inventronics GmbH declares that the radio
equipment types OTi DALI 35/220-240/700 NFC TW L and OTi DALI
75/220-240/1A4 NFC TW L are in compliance with Directive 2014/53/
EU and the relevant statutory instruments. The full text of the EU
declaration of conformity or the UK-declaration of conformity is avail-
able at the following internet address: www. inventronicsglobal. com.
Frequency range: 13 553 – 13 567 kHz. Technical support:
www. inventronicsglobal. com. 1) Constant current LED Power Supply;
2) t c point; 3) Connect PE to case or PIN 3; wire preparation; push in;
4) Designed and engineered in Germany/Italy; Made in Bulgaria or
China 5) picture only for reference, valid print on product; 6) Mains
(PIN 1, PIN 2); 7) Input; 8) Output; 9) Year; 10) Week
2) 4)
OTI
35W
NFC NFC
TW L TW L
B16
30 x
B10
19 x
T 180 μs 210 μs
H
V AC
198 – 264 V
N
V DC 176 – 276 V
N
OTI
75W
20 x
13 x
