ADJUSTMENTS
Positive 0° Bevel Stop
See Figure 22, page 22.
The saw has a positive 0° bevel stop that has been factory
adjusted to assure 0° angle of the saw blade when making 0°
cuts. However, misalignment can occur during shipping.
To check positive 0° bevel stop:
• Remove the battery pack from the tool.
• Place the saw in an upside down position on a workbench.
• Move the lower blade guard out of the way so that the saw
blade is exposed.
• Check the squareness of the saw blade to the base of the saw
using a combination square.
MAINTENANCE
WARNING:
When servicing, use only identical replacement parts. Use of any
other part could create a hazard or cause product damage.
WARNING:
Always wear eye protection with side shields marked to comply
with ANSI Z87.1 or equivalent standard. Failure to do so could
result in objects being thrown into your eyes and other possible
serious injuries.
WARNING:
To avoid serious personal injury, always remove the battery pack
from the tool when cleaning, performing any maintenance, or
when storing the tool.
To adjust positive 0° bevel stop:
• Remove the battery pack from the tool.
• Rotate the bevel lock lever counterclockwise to release.
• Insert a 2.5 mm hex wrench (not provided) through the screw
hole in the saw base.
• Turn adjustment screw with 2.5 mm hex wrench (not provided)
and adjust base until it is square with the saw blade.
• Securely lock the bevel lock lever.
WARNING:
Attempting a bevel cut without having the bevel lock lever
securely locked in place can result in serious injury.

General Maintenance

Avoid using solvents when cleaning plastic parts. Most plastics
are susceptible to damage from various types of commercial
solvents and can be damaged by their use. Use clean cloths to
remove dirt, dust, oil, grease, etc.
WARNING:
Do not at any time let brake fluids, gasoline, petroleum-based
products, penetrating oils, etc., come in contact with plastic
parts. Chemicals can damage, weaken or destroy plastic which
could result in serious personal injury.
