KEY Active systems Sep 2018
Fig.12. "HR" flying bar for KEY cabinets
3.7.4. KEY18WA flying
This model is not prepared for flying.
3.8. KEY grille
To remove the front grille, first remove the
screws on the left side.
Fig.13. Grille screws

4. SYSTEM SETUP

Thanks to their internal microcontroller and DSP System, the KEY Active cabinets
can be configured for different applications. This section explains all the possible
configurations.
The LCD and keypad on the cabinet's back panel are used for the setup.
IMPORTANT: To enter the Menu, the keypad must be unlocked by
simultaneously pressing the keys MENU and SELECT
4.1 Startup and Main Screen
At startup the LCD screen will show the Amate Audio and KEY logo. After a few
seconds, the main screen shown in Fig. 14 will be displayed:
