7.2 Removing Brake Configurations


Reference exploded view in section
!
8.3 for numbering and descriptions.
Remove the rear wheel per section 5.1.
Removing Roller Brake Hardware
1. Remove left hand axle nut (1), left hand
no-turn washer (2), and left hand nut (3).
2. Secure the wheel and use service tool
N360T-BKAD-01 to remove the brake
lock ring (6), and remove the roller brake
adapter (7) from the CVP.
Removing Rim Brake Hardware
1. Remove left hand axle nut (1), left hand
no-turn washer (2), left hand nut (3), and
cupped washer (4).
2. Using a thin flat device, pry and remove
the rim brake cover (5).
Removing Disc Brake Hardware
1. Remove left hand axle nut (1), left hand
no-turn washer (2), left hand nut (3), and
cupped washer (4).
2. Secure the wheel and use service tool
N360T-BKAD-01 to remove the brake lock
ring (6), and remove both the brake shield
(8) and disc brake adapter (9) from the
CVP.
