Exploded View - NuVinci OPTIMIZED harmony 330 Manual Del Propietário Y Guía

8.3 Exploded View

4 5
A
1 3
B
6
2
C
4
8
TECHNICAL OWNER MANUAL
Left (non-drive) side Right (drive) side
7
9
(Optional – to be
used with 2.3 mm
thick sprockets)
19 17 15 13 11
18 16 14 12 10
Not supplied
HARMONY TECHNICAL DATA
A Rim brake configuration
2
B Roller brake configuration
Disc brake configuration
C
1 Axle nut
2 No-turn washer
3 Left hand nut
4 Cupped washer
5 Rim brake cover
6 Brake lock ring
7 Roller brake adapter
8 Brake shield
9 Disc brake adapter
10 R.h.nut
11 Hub Interface
12 Sprocket snap ring
1
13 Sprocket spacer
14 Sprocket
15 Snap ring (freewheel)
16 Freewheel assy
17 Snap ring (interior)
18 Needle bearing
19 R.h. shield
EN
25
