Jacobsen HR 4600 Turbo Manual De Piezas Y Mantenimiento página 177

Item Part No. Qty.
1 1002857
557759
2 366879
3 1003239
4 1003260
5 1003261
6 164102
7 558021
8 303962
9 403740
10 3006797
11 3007719
12 400108
13 445794
14 444718
15 452006
16 363485
17 366884
18 362263
19 361695
20 400188
21 400272
22 444762
23 446136
24 445795
25 364501
26 3008383
27 363586
28 446134
29 367031
30 3010575
Description
1 Engine, Kubota V1505-TE
1 • Engine Oil Filter
3 Isolator, Engine
1 Front Engine Mount
1 Left Side Engine Mount
1 Right Side Engine Mount
1 Cable, Throttle
1 • Clip
1 • Wire Stop
1 • • Screw, #8-32 x 1/2" Hex Head
1 Bracket, Cable Mounting
1 Pivot, Throttle Cable
1 Screw, 1/4-20 x 3/4" Hex Head
1 Nut, 1/4-20 Spiralock Flange
1 Locknut, 5/16-18 Center
3 Flat Washer, 5/16
10 Lockwasher, M10 Heavy
9 Screw, M10-1.25 x 20mm Hex Head
2 Screw, M10-1.25 x 25mm Hex Head
2 Screw, M80-1.25 x 110mm Hex Hd
7 Screw, 5/16-18 x 1" Hex Head
3 Screw, 3/8-16 x 2-1/4" Hex Head
3 Locknut, 3/8-16 Center
2 Lockwasher, 5/16 Heavy
7 Nut, 5/16-18 Spiralock Flange
1 Temperature Sender
2 Clip, Wire Harness
1 Screw, M8-1.25 x 20 mm Hex Head
1 Lockwasher, 5/16
3 Washer, Isolator
1 Spacer, Isolator
HR-4600
Serial Numbers/Notes
> Change from previous revision
51
