Description Of The Machine - La San Marco NEW 105 E Manual De Uso

2.1 Description of the machine
Note: The terms used in this description will commonly be used throughout the following pages.
1
Figure 1
LegeNDA:
1) Main switch
2) espresso coffee serving unit
3) Filter cup with handle
4) Double-scale pressure gauge
5) Tray and cup support grill
6) electronic level
7) Steam spout
8) burn protection sheath
9) Hot water spout
10) Steam drawing vlve knob
11) 6 key keypad
12) Upper cup support tray
28
12 11
2 3
10
4 9
8
7
5
