6 Electrical installation
PROFINET connection
Ethernet cable specifications
)
Note!
Only use cables complying with the below specifications.
Ethernet cable specifications
Ethernet standard
Cable type
Damping
Crosstalk damping
Return loss
Surge impedance
42
Standard Ethernet (according to IEEE 802.3), 100base TX (fast
Ethernet)
S/FTP (Screened Foiled Twisted Pair), ISO/IEC 11801 or EN 50173,
CAT 5e
23.2 dB (at 100 MHz and per 100 m)
24 dB (at 100 MHz and per 100 m)
10 dB (per 100 m)
W
100
l
EDK94AYCER DE/EN/FR/ES/IT 6.1
