SPECIFICATIONS

Analog Inputs
Main Output
Control Room Output
Multi Outputs
Phones
Sampling Frequency
Signal Delay (CH INPUT to STEREO OUT)
Distortion (THD + N)
Frequency Response
(CH INPUT to STEREO OUT)
Hum & Noise
VGA Monitor output
Ethernet 10/100 Base
USB 2.0 (Mouse/Flash Drive)
USB 2.0 (Audio)
Power Supply Unit
Dimensions (H x W x D)
Weight
28
12 x XLR Balanced (Ch 1-12)
4 x Combo (XLR/TRS) Balanced (Ch 13-16)
2 x XLR Balanced
2 x TRS Balanced
4 x TRS Balanced
1 x Stereo Phone Jack (TRS Unbalanced)
44.1 kHz, 48 kHz (40-Bit floating point mixing)
Fs=48 kHz <1.2ms
THD+N less than 0.007%, +4 dBu,
20-20 kHz, unity gain, 20 kHz BW
Fs=48kHz, 0/-1.5dBu,
20 Hz – 20 kHz @ +4dBu into 600Ω
(20 Hz – 20 kHz), Rs=150, -128dBu (EIN), -90dBu
(residual output noise)
D-Sub 15 pin: 800x600@60Hz (SVGA)
RJ45
Type A
Type B (2 x 2 Interface)
Selectable from CH1-16, CTRL RM, MAIN
100V - 240V, 50/60Hz, 90W
82 x 324 x 393 mm (3.2" x 12.8" x 15.5")
2.8 kg (6.2 lbs)
Acapela 16
