Overview Of The Control Panel - Samsung DV405 Serie Manual De Usuario

operating Instructions, tips
To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFTY
INSTRUCTION before operating this appliance.
WARNING

OVERVIEW OF THE CONTROL PANEL

DV405*
DV398*
DV395*
DV393*
Cycle Selector
1
DV405ETPAWR_03021F-09_EN.indd Sec13:22 DV405ETPAWR_03021F-09_EN.indd Sec13:22
1 2 3
To select a cycle, rotate the Cycle Selector dial to the desired cycle.
The indicator light by the cycle name will illuminate. The Normal, Heavy Duty, Perm Press,
Towels, Bedding PLUS / Bedding, Delicates, Wool and Sanitize cycles are Sensor Dry cycles.
Sensor Dry automatically senses the moisture in the load and shuts the dryer off when the
selected dryness level (very dry to damp dry) is reached.
Normal – Use this cycle to dry loads such as cotton, underwear, and linen.
Heavy Duty – Use this cycle to get high heat for heavy fabrics such as jeans, corduroys, or
work clothes.
Perm Press – Dry wrinkle-free cottons, synthetic fabrics, knits, and permanent press fabrics
automatically.
Towels – Dry loads such as bath towels.
Bedding PLUS / Bedding – For bulky items such as blankets, sheets and comforters.
Delicates – The Delicates cycle is designed to dry heat-sensitive items at a low drying
temperature.
Wool – For machine washable and tumble dryable wool only.
English - 22
4 5 6 7 8 9
