Intended Use

Electric water heater (hereinafter referred to as EWH) is designed to provide hot water to household
and industrial facilities that have a cold water supply pipeline with the parameters shown in the table
«Basic Technical Specifications.»
The EWH shall be operated in closed heated rooms and shall not be intended for operation in
continuous flow mode.

Main Technical Specifications

Pressure in the cold water line, min/max
Power supply network – ingle-phase, voltage, frequency
EWH Wattage
Diameter of the threads of the cold and hot water connection pipes
Protection class of the water heater
Operation at ambient temperature
Adjustment range of water heating temperature
Accuracy of temperature maintenance in storage mode
The manufacturer reserves the right to change the design and characteristics of the water heater
without prior notice.
Information concerning the application area and the method of determining the manufacture
date:
The release date of the product is encoded in a unique serial number located on the identification
plate (sticker) placed at the bottom of the product. The serial number of the product consists of
thirteen digits. The third and fourth digit of the serial number represent the year of issue, the fifth and
sixth – the month of release, the seventh and eighth –the day of the EWH release date.
Indication of security measures
1. All installation, plumbing, and electrical work shall be carried out by qualified personnel
only!
2. Electrical safety and anti-corrosion protection of the EWH are only guaranteed upon availability of
efficient grounding performed in accordance with the current Electrical Installation Regulations (EIR).
0,05 / 0,8 MPa
~230 V (±10%), 50 Hz
1500 W
G1/2
IPX4
+3...+40 °С
+30...+74 °С
±5 °С
