Always make sure that the bell is completely immer-
sed to avoid splashing and that the ventilation
openings in the motor housing do not come into
contact with any liquid!
For optimum efficiency two thirds (2/3) of the tube
should be immersed in the product.
• Whisk operation
We recommend that you hold the power mixer by
the handle and the bottom of the motor unit.
You can also hold the
appliance by the handle
with one hand, leaving
the other hand free to
hold the bowl, if neces-
sary.
While processing we re-
commend that you move
the whisk around in the
bowl, in order to ensure
that the mixture is com-
pletely homogeneous.
We strongly advise you
to keep the whisk from
touching the sides of the
bowl. For maximum effi-
ciency, at least one-fifth
of the whisk length
should be immersed.
We also strongly advise
you to start the proces-
sing at a low speed.
ASSEMBLY /
DISASSEMBLY
- BLADE
• Attaching the tube to the motor unit.
(only for CMP Combi)
- Unplug the machine then, align the flat side of
the conical part of the tube with catch
aluminum casing.
- Insert the narrow portion of conical part
tube into the aluminum casing.
- Turn the tube in the direction of the arrow (see fi-
gure) until it is snugly in place.
• Removing the tube from the casing
- Unplug the power mixer.
- Turn the tube in the opposite direction of that used
to attach it.
- When it will not go any further, remove the tube
from the conical part.
TURN TO ATTACH BELL
• Attaching the bell to the tube
- Unplug the power mixer.
- Align the flat side of
tube with catch
on the inside of the bell.
B
- Insert the conical part
washer touching the tube seal
the direction of the arrow (See figure) to lock the
bell lug
and tube lug
E
A
in the
B
of the
C
E
F
the conical part of the
A
C
into the bell. With the
, turn the bell in
D
snugly together.
F
1
2
7
