1. Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a
carpeted floor or the empty carton to avoid any scratch.
2. Securely screw the Cam Bolts (2) into the threaded bushing on the Desk Top (A) and Riser Top (B) as
shown.
C
3. Insert two Wood Dowels (3) into the inner holes against the cable channel of the Upper Back Panel (C).
Make sure that you use a small amount of glue with both ends of all dowels.
4. Align and attach the Upper Back Panel (C) to the Riser Top (B) by engaging two Cam Locks (1) (Refer
to page 3 on Cam Lock system operation supplement).
Assembly Instructions
A
B
B
7
2
C
1
B
3
