Power Supply Connection

The MCB-45W is designed for 12V DC operation
in vehicles with NEGATIVE (-) GROUND electrical
systems. Most domestic and foreign made cars and
trucks use a negative ground system. NOTE: If your
negative (-) battery terminal is connected to the
motor block of your vehicle, it is a negative ground
system.
CAUTION: Do not attempt to connect your
MCB-45W to a POSITIVE (+) ground vehicle
as damage may occur to the CB unit and/or to
your vehicle's electrical system.
NOTE: Check your vehicle's ground requirements
before you begin the installation!
Your MCB-45W should be connected using the
following steps:
1) Move the off/on-volume control to the "off"
position. CAUTION: If the off/on-volume
control is in the "on" position without an
antenna hook-up, it could result in damage
to the transmitter circuitry.
2) Disconnect the cable from your vehicle
battery's negative (-) terminal.
3) Connect the black GROUND wire to a metal
part of your vehicle's frame.
NOTE: Be sure the metal part is not insulated from
the vehicle's frame by a plastic part.
4) Connect the red (to switched accessory) wire
to a source of voltage that turns on and off with
the ignition switch, such as a spare accessory
terminal in your vehicle's fuse box.
