To remove the upholstery & safety harness for
cleaning, follow the instructions given in the care
& maintenance section of this instruction guide.
(a6-a) Safety Bar Assembly
– (#06) Insert the safety bar into the plastic
round joint on either side of the frame. You
will hear audible clicks. Check the safety bar
is secured by pulling it outwards.
– Fit the crotch bar base through the slit on
the upholstery to position it onto the metal
tubing. Secure the crotch bar by closing the
clamp over the metal tubing. You will hear an
audible click. Check the crotch bar is secured
by putting it outwards.
Remove Safety Bar
– Unlock the crotch bar by opening the clamp
on the base.
– Use a pen to press the small pin of the round
joint on either side of the frame.
– Pull and remove safety bar.
For USA nano bloom urban highchair (b6)
– (#07) The USA safety bar design is different
from other versions according to USA safety
standard requirements.
– Please follow the specific procedures (b6-a7)
to assemble the USA safety bar.
– Other than the safety bar section, follow
all other general procedures given in this
instruction guide for your USA nano bloom
urban highchair in the same fashion.
WARNING:
Do not disassemble the USA crotch bar.
(a-a) Using And Adjusting The Safety
Harness
Locking the Safety Harness:
(#04) Lock the harness by pushing the tongues
on the ends of the waist straps, connected with
the ends of the shoulder straps, into the buckle
on the crotch strap.
The harness will automatically lock when the
tongues have been fully pushed in. You will hear
an audible click.
Unlocking the Safety Harness:
Squeeze the ends of the tongues together and
then slide them out of the buckle. Your child can
now be removed form the highchair.
Adjusting the Shoulder Straps Height
As your child grows you will need to alter the
height of the shoulder straps. The time to do this
is when the child's shoulders are above the slits
on the upholstery, where the shoulder straps
pass through.
Note: Every time you place your child in the
highchair always check that the harness is
correctly fitted and adjusted using the shoulder
and waist strap buckles. Tighten the harness
until it fits snugly around your child.
(a10-a14) Food Tray Assembly
– (#05) Under the food tray are two locks, slide
the buttons whilst rotating the locks open.
