Operation
3. To raise or aerate the soil, tilt engine closer to the ground
which will raise cultivator tines higher relative to the soil sur-
face.
IMPORTANT
Do not operate cultivator underwater. The gear housing is not
sealed and water will wash away lubrication damaging gears,
bearings, and seals.
Resetting tines for deep cultivation
 The tines are factory assembled with blade ends offset for
standard cultivation. For deep cultivation, the left tine (viewed
from the operator's position) must be repositioned on the hub
aligning the left and right tine blade ends directly across from
each other.
1. Remove three (3) bolts (A) mounting left tine to hub. The
bolts will be mounted in hole labeled (1).
2. Rotate tine counter clockwise and position hole labeled (2)
over hub mounting holes. The tine blade ends should be
aligned directly opposite each other.
3. Install and tighten bolts.
12
