Safety - durher Ordesa M Manual De Instrucciones

4.Check the correct voltageof the mains
supply.
5.Connect the aereal base to the current
supply box of the machine.
6.Press the 'start' switch of the machine.
7.If the malfunctioning continues, the machi-
ne will have to be repaired by the Technical
Service.
FAILURE IN ONE OF THE MOTOR PHASES
1.Operate the 'stop' push button of the
machine.
2.Disconnect the aereal base of the current
supply box of the machine.
3.Check the correct voltage of the mains
supply.
4.Connect the aereal base to the current
supply box of the machine.
5.Press the 'start' switch of the machine.
6.If the malfunctioning continues, the
machine will have to be repaired by the
Technical Service.
MISALIGNMENT OF THE CUTTING DISC
1.Operate the 'stop' push button of the
machine.
2.Disconnect the aereal base of the current
supply box of the machine.
3.Remove the bolts fixing the top of the
lower cover and open the top.

8. Safety

SUMMARY OF SAFETY NOTICES
The following advice have been drafted in order
to avoid accidents of the operator with the
machine. For safety reasons, carefully read
4.Check the correct tightening of the cut-
ting blade nut with the motor shaft.
5.In the event that the tightening is correct,
check the possible blade warp.
6.For this purpose, loosen the fixing nut of
the blade, extract the blade and place it
on a flat surface. If the blade is curved,
discard it and install a new one.
7.Make sure that the blade and tightening
of the nut is correct.
8.Close the top of the lower cover and
screw the two fixing bolts.
9.If the malfunctioning continues, the machi-
ne will have to be repaired by the Technical
Service.
RESISTENCE WHEN CUTTING
1.Operate the 'stop' push button of the
machine.
2.Disconnect the aerial base of the current
supply box of the machine.
3.Check the condition of the cutting discs,
the blade warp (see previous point) and
the cleaning of the disc.
4.In the event that the dismanteling of the
blade disc is necessary, remove the fixing
bolts from the lower cover and open the top.
5.Clean the blade and carry out the pre-
vious operations in the reverse order to
close the cover top. In the event of dis-
manteling the blade, follow the previous
point instructions.
the advice and the rest of the Manual.
Read the Instructions Manual thouroughly
before assembling and using the machine.
45
