HZ-2800_OM_Rev0.qx
4/25/05
IMPORTANT SAFETY
INSTRUCTIONS
When using electrical appliances, basic
precautions should always be followed to
reduce the risk of fire, electric shock, and
injury to persons, including the following:
1. Read all instructions before using this heater.
2. This heater is hot when in use. To avoid burns,
do not let bare skin touch hot surfaces. If
provided, use handle when moving this heater.
Keep combustible materials, such as furniture,
pillows, bedding, papers, clothes, and curtains at
least 3 feet (0.9 m) from the front of the heater
and keep them away from the sides and rear.
3. Extreme caution is necessary when any heater is
used by or near children or invalids and whenever
the heater is left operating and unattended.
4. Always unplug heater when not in use.
5. Do not operate any heater with a damaged cord
or plug or after the heater malfunctions, has been
dropped or damaged in any manner.
6. Do not use outdoors.
7. This heater is rated at 1500W, 120 VAC. It is
intended for use on tabletops or desktops and
floors. It is not to be used in wet or moist
locations, such as bathrooms and laundry areas.
If an extension cord must be used, it must be 14
gauge or larger and rated no less than 1875
watts.
8. Do not run cord under carpeting. Do not cover
cord with throw rugs, runners, or the like.
Arrange cord away from traffic area where it will
not be tripped over.
9. This appliance has a polarized plug (one blade is
wider than the other). To reduce the risk of
shock, this plug is intended to fit only one way in
a polarized outlet. If the plug does not fit
The Honeywell trademark is used by Kaz, Inc. under license from Honeywell Intellectual Properties, Inc.
2:38 PM
Page 1
H
EATER
Model HZ-2400 Series
Model HZ-2410 Series
Model HZ-2800 Series
securely in the outlet, reverse the plug. If it still
does not fit, contact a qualified electrician.
DO NOT attempt to defeat this safety feature.
10. This heater draws 12.5 amps during operation
when in the high setting. To prevent overloading
a circuit, do not plug the heater into a circuit that
already has other appliances working.
11. It is normal for the plug to feel warm to the touch;
however, a loose fit between the AC outlet
(receptacle) and plug may cause overheating and
distortion of the plug. Contact a qualified
electrician to replace loose or worn outlet.
12. To disconnect the heater, first turn controls to the
OFF position, then grip the plug and pull it from
the wall outlet. Never pull by the cord.
13. Do not insert or allow foreign objects to enter any
ventilation or exhaust opening as this may cause
an electric shock or fire, or damage the heater.
14. To prevent a possible fire, do not block air intakes
or exhaust in any manner. Do not use on soft
surfaces, like a bed, where openings may
become blocked.
15. A heater has hot and arcing or sparking parts
inside. Do not use it in the areas where gasoline,
paint, or flammable liquids are used or stored.
16. Use this heater only as described in this manual.
Any other use not recommended by the
manufacturer may cause fire, electric shock, or
injury to persons.
17. The output of this heater may vary and its
temperature may become intense enough to burn
exposed skin. Use of this heater is not
recommended for persons with reduced
sensitivity to heat or an inability to react to avoid
burns.
SAVE THESE
18.
INSTRUCTIONS
F
AN

Publicidad

Tabla de contenido
loading

Resumen de contenidos para Honeywell HZ-2400 Serie

  • Página 1 To reduce the risk of shock, this plug is intended to fit only one way in a polarized outlet. If the plug does not fit The Honeywell trademark is used by Kaz, Inc. under license from Honeywell Intellectual Properties, Inc.
  • Página 2: Other Features

    All manuals and user guides at all-guides.com HZ-2800_OM_Rev0.qx 4/25/05 2:38 PM Page 2 OPERATION / USING THE THERMOSTAT FEATURE • Place the heater on a firm, level surface free from Fig. 1 obstructions, and at least 3 ft. (0.9m) away from any wall, furniture or combustible material.
  • Página 3 All manuals and user guides at all-guides.com HZ-2800_OM_Rev0.qx 4/25/05 2:38 PM Page 3 TROUBLESHOOTING If your heater shuts off unexpectedly or fails to operate, one of your heater safety features may have been activated to prevent overheating. • Be sure it is plugged in and that the electrical outlet is working. •...
  • Página 4 All manuals and user guides at all-guides.com HZ-2800_OM_Rev0.qx 4/25/05 2:38 PM Page 4 5 YEAR LIMITED WARRANTY You should first read all instructions before C. This warranty does not cover damage resulting attempting to use this product. from any unauthorized attempts to repair or from any use not in accordance with the A.
  • Página 5: Importantes Instructions De Sécurité

    Éloigner le cordon des endroits très passants et de là où l'on risquerait de trébucher dessus. INSTRUCTIONS 9. Cet appareil est équipé d'une fiche polarisée (fiche dont l'une La marque de commerce Honeywell est utilisée par Kaz, Inc. avec l'autorisation de Honeywell Intellectual Properties, Inc.
  • Página 6: Fonctionnement - Utilisation De La Fonction Thermostat

    All manuals and user guides at all-guides.com HZ-2800_OM_Rev0.qx 4/25/05 2:38 PM Page 6 FONCTIONNEMENT - UTILISATION DE LA FONCTION THERMOSTAT • Placer l'appareil de chauffage sur une surface dégagée, ferme et bien Fig. 1 horizontale, à une distance d'au moins 0,9 m (3 pi) de tout mur ou matière combustible.
  • Página 7: Service À La Clientèle

    All manuals and user guides at all-guides.com HZ-2800_OM_Rev0.qx 4/25/05 2:38 PM Page 7 DÉPANNAGE Si l'appareil de chauffage s'éteint inopinément ou ne fonctionne plus, c'est peut-être qu'une des caractéristiques de sécurité de l'appareil a été activée afin d'éviter une surchauffe. •...
  • Página 8: Garantie Limitée De 5 Ans

    All manuals and user guides at all-guides.com HZ-2800_OM_Rev0.qx 4/25/05 2:38 PM Page 8 GARANTIE LIMITÉE DE 5 ANS Prière de lire toutes les instructions avant C. Cette garantie ne couvre pas les dommages detenter d'utiliser ce produit. découlant des tentatives de réparation non autorisées ou de toute utilisation non conforme A.
  • Página 9: Radiador-Ventilador

    él. INSTRUCCIONES. 9. Su radiador viene con un enchufe polarizado (una patilla más ancha que otra). Para minimizar el riesgo de choque Kaz, Inc. utiliza la marca de comercio Honeywell con autorización de Honeywell Intellectual Properties, Inc.
  • Página 10: Funcionamiento - Cómo Usar El Termostato

    All manuals and user guides at all-guides.com HZ-2800_OM_Rev0.qx 4/25/05 2:39 PM Page 10 FUNCIONAMIENTO - CÓMO USAR EL TERMOSTATO • Coloque el radiador en una superficie libre de obstáculos, firme y Fig. 1 llana, a una distancia de al menos 3 pies (0,9 m) de toda pared o materia combustible.
  • Página 11: Atención Al Cliente

    All manuals and user guides at all-guides.com HZ-2800_OM_Rev0.qx 4/25/05 2:39 PM Page 11 PROBLEMAS Si el radiador se apaga repentinamente o deja de funcionar, puede que uno de los dispositivos de seguridad esté activado para evitar su sobrecalentamiento. • Asegúrese que el radiador está enchufado y que la toma de corriente funciona. •...
  • Página 12: Garantía Limitada De 5 Años

    All manuals and user guides at all-guides.com HZ-2800_OM_Rev0.qx 4/25/05 2:39 PM Page 12 GARANTÍA LIMITADA DE 5 AÑOS Por favor, lea todas las instrucciones antes de C. Esta garantía no cubre los daños ocasionados usar el radiador. por tentativas de reparación no autorizadas o por el uso no conforme con el presente A.
