Circuit Diagram

Lithium battery

Manufacturer Information

Manufacturer
Address
Disposal
The machine, accessories and packaging should be sorted for environmental-friendly recycling.
Do not dispose of the machine into household waste!
Display screen
assembly
Infrared
Charger
transmitter PCB
Infrared receiving
PCB
Lithium battery
PCB
Speaker louder
Kingclean Electric Co., Ltd
No.1 Xiangyang Road, Suzhou New District, Jiangsu
Province 215009, China
PCB assembly
-
+
M
Vacuum motor Floor head motor
Display PCB
assembly
-
+ M
